Test Product 4

Festool Cordless pendulum jigsaw PSC 500 EB-Basic

splinterguard, extractor connector, jigsaw blade set: 1 x WOOD FINE CUT S 75/2.5 and 1 x WOOD UNIVERSAL S 75/4 FSG, Systainer SYS3 M 187Centre 26.00 mm; Battery voltage (rated voltage) 18.00 V; Stroke rate 1500 - 3800 min⁻¹; Pendulum cover adjustment in stages 4; Stroke length 26.00 mm; Cutting depth in wood 120.00 mm; Cutting depth in NF metals 20.00 mm; Cutting depth in steel (soft) 10.00 mm; Max. inclined position (both sides) 45 °; Drive type Battery; Product weight without accessories 2.30 kg; Transport weight incl. accessories 4.8 kgSawing chipboard: Total vibration average, Ah 7.00 m/s²; Sawing chipboard: Standards series EN 62841; Sawing chipboard: Uncertainty (noise) K 5.00 dB; Sawing chipboard: Uncertainty (vibration) K 1.50 m/s²; A-weighted sound pressure level, LpA 91.00 dB(A); Sawing chipboard: A-weighted sound power level, LWA 99.00 dB(A)

Superior jigsaws.

Strengths and benefits

• Versatile: excels in large cross-sections in solid wood, tight curves or angled cuts with a cutting depth of up to 120 mm and intelligent accessories.
• Precise: Enhanced three-point guidance and guiding jaws ensure accurate, angle-true cuts.
• Powerful: Consistent torque thanks to an advanced machine concept – effortless even with large cross-sections in solid wood.
• Unobstructed view: Blowing function, deactivatable lighting and extraction ensure a clear view of the scribe mark.
• Time-saving: Tool-free FastFix saw blade replacement saves time and facilitates uninterrupted work.
• Optimal cutting quality: The splinter guard minimises splintering on both sides – delivering clean cut edges and reducing the need for reworking.
• Suitable for the material: Adjustable speed and automatic startup for precise operation and efficient cuts.
• Sawing progress: The pendulum stroke can be promptly adjusted to meet the specific requirements – ensuring swift feed and accurate results.
• Angle-accurate: The table can be adjusted for angled cuts and locks at 0° – for precise 90° cuts.
• Stay Connected: Access operating data, accessories, and extractor control via Bluetooth and the Festool app.

Main areas of use

• Precise separation and adjustment cuts in wooden components such as beams, rafters, and purlins up to 120 mm.
• Precise cutting of formwork, terrace boards and stair treads to exact contours.
• Cutting insulation and sandwich panels with steel/OSB facings.
• Customisation work on furniture, kitchens, interior fittings.
• Cut-outs for sinks and kitchen hobs
• Cutting circles and curves
• Slanted cuts.

Delivered parts
splinterguard, extractor connector, jigsaw blade set: 1 x WOOD FINE CUT S 75/2.5 and 1 x WOOD UNIVERSAL S 75/4 FSG, Systainer SYS3 M 187
